Product characteristics

• 45A 250V 13A 250V~
• Screw terminals accept wires up to 16mm²
• For BS type 47 mm 2 gangs flush mounting boxes
• Screwless cover plate is square 86x146 mm, product thickness is 4mm (once is installed onto the wall).
• Complete product, cover plates are clipped onto the mechanism itself.


Recommendation / Restriction

• Recommended inside use only


The product's benefits
Installation

• Compact mechanisms for maximum wiring space and slim front plates.


Advantages

• Plate and rocker are made in the same ferritic Stainless Steel - Grade 430, with a chromium plating which bring a better rusting resistance and a nicer finish
• Oblong blue led power indicator which size is 11mm x 1,5mm, LED technology ensures the maximum quality in terms of reliability, efficiency, maintenance and energy saving
• Delivered with screws for flush & surface boxes in both plastic and metal boxes.


Technical characteristics

• Type of switch: Off switch

• Type of socket outlet: British Standard

• Number of socket outlets: 1

• Method of operation: Rocker/button

• Mounting direction: Horizontal

• Type of fastening: Mounting with screw

• With lighting: Yes

• Mounting method: Flush-mounted

• Material: Metal

• Material quality: Stainless steel

• Halogen free: Yes

• Surface protection: Metallic

• Surface finishing: Glossy

• Colour: Stainless steel, Gold

• Transparent: No

• Suitable for degree of protection (IP): IP2X

• Nominal voltage: 250 V

• Nominal current socket outlet: 13 A

• Rated current: 13 A

• Device width: 146 mm

• Device height: 86 mm

• Device depth: 35 mm

• Compatible with Apple HomeKit: No

• Compatible with Google Assistant: No

• Compatible with Amazon Alexa: No

• IFTTT support available: No

• Built-in depth: 24 mm

• Degree of impact strength (IK): IK01

• Operating / setting temperature: -5-40 °C

• Storage temperature: -5-40 °C

• Voltage type: AC

• Antimicrobial treatment: No

• Connection type: Screwed terminal

• Cable section: 10-10 mm²
