Technical characteristics

• Assembly arrangement: Basic element with complete housing

• Method of operation: Turn button

• Number of modules (module system): 2

• App control via Bluetooth: No

• Dimming phase cut-on: Yes

• Dimming phase cut-off: Yes

• Serial dimmer: No

• Type of load: Universal and LED Retrofit

• Substation input: No

• Light value memory: No

• Applicable with button: Yes

• Applicable with movement sensor: No

• Applicable with presence indicator: No

• Applicable with time switch/timer: No

• Applicable with transmission button: No

• Applicable with infrared button: No

• Mounting method: Flush-mounted

• Type of fastening: Mounting with screw

• Material: Plastic

• Material quality: Thermoplastic

• Halogen free: Yes

• Surface protection: Untreated

• Surface finishing: Glossy

• Colour: White

• Transparent: No

• Suitable for degree of protection (IP): IP40

• Degree of impact strength (IK): IK02

• Nominal voltage: 100-240 V

• Frequency: 50-60 Hz

• Nominal power resistive load: 5-300 W

• Connection type: Screwed terminal
• Cable section: 1-6 mm²

• Device width: 86 mm

• Device height: 88 mm

• Device depth: 32 mm

• Min. depth of built-in installation box: 40 mm

• Compatible with Apple HomeKit: No

• Compatible with Google Assistant: No

• Compatible with Amazon Alexa: No

• IFTTT support available: No

• Built-in depth: 32.6 mm

• Operating / setting temperature: -5 to 45 °C

• Storage temperature: -10 to 70 °C

• Voltage type: AC

• Mandatory neutral: No

• Terminal marking indication: No

• Stress test conformity (1000V): Yes

• Antimicrobial treatment: No

• Terminals capacity: 1-6 mm²
