Product characteristics

• Supply : 230V~ 50/60Hz Output : 230V~ or 120V~ - 20VA max
• Back box to be min. 45mm deep
• Conform to BS EN 61558
• Screwless cover plate is square 146x86 mm, product thickness is 4mm (once is installed onto the wall).
• Complete product, cover plates are clipped onto the mechanism itself.


Recommendation / Restriction

• Recommended inside use only.


The product's benefits
Installation

• Screwless live and neutral terminals.


Advantages

• Plate in austenitic stainless steel Non-magnetic Grade 304L
• Made in UK
• Delivered with screws for flush & surface boxes in both plastic and metal boxes.

Technical characteristics

• Assembly Arrangement: Cover plate

• Mounting Method: Flush-mounted

• With Hinged Lid: No

• Voltage Reversible: Yes

• Nominal Voltage Low Value: 115 V

• Nominal Voltage High Value: 240 V

• Material: Metal

• Material Quality: Stainless steel

• Halogen Free: Yes

• Surface Protection: Metallic

• Surface Finishing: Glossy

• Colour: Stainless Steel, Gold

• Transparent: No

• Device Dimensions:
• Width: 86 mm
• Height: 146 mm
• Depth: 45 mm
• With Built-in Installation Box: No
• Min. Depth of Built-in Installation Box: 50 mm
• Built-in Depth: 41 mm
• Degree of Impact Strength (IK): IK02
• Degree of Protection (IP): IP24
• Operating/Setting Temperature: -5°C to 40°C
• Storage Temperature: -5°C to 40°C
• Voltage Type: AC
• Antimicrobial Treatment: No
• Connection Type: Push-in clamp
