Technical characteristics

• Connection type    Screw connection

• Mounting method    Other

• Type of current    AC

• Rated current    13 A

• Rated voltage    250 V

• Dimensions glass fuse    5x25 mm

• Width    86 mm

• Height    86 mm

• Depth    32 mm

• Built-in depth    25.1 mm

• Degree of impact strength (IK)    IK04

• Degree of protection (IP)    IP20

• Operating / setting temperature    -5-50 °C

• Storage temperature    -10-70 °C

• Voltage type    AC

• Nominal voltage    250-250 V

• Supply current    13-13 A

• Frequency    50-60 Hz

• Mandatory neutral    Yes

• Terminal marking indication    Yes

• Colour    White

• RAL-number    9003

• Halogen free    Yes

• Antimicrobial treatment    No

• Number of terminals    5

• Terminals capacity    1-4 mm²

• Cable nature for connection    Flexible or rigid

• Cable section    1-4 mm²
