Technical characteristics

• Assembly arrangement: Basic element with adapter plate

• Method of operation: Turn button

• App control via Bluetooth: No

• Dimming phase cut-on: Yes

• Dimming phase cut-off: Yes

• Serial dimmer: Yes

• Type of load: Resistive load

• Substation input: No

• Light value memory: Yes

• Applicable with button: No

• Applicable with movement sensor: No

• Applicable with presence indicator: No

• Applicable with time switch/timer: No

• Applicable with transmission button: No

• Applicable with infrared button: No

• Mounting method: Flush-mounted

• Type of fastening: Mounting with screw

• Material: Plastic

• Material quality: Thermoplastic

• Halogen free: Yes

• Surface protection: Lacquered

• Surface finishing: Matt

• Colour: Black

• Transparent: No

• Suitable for degree of protection (IP): IP20

• Degree of impact strength (IK): IK04

• Nominal voltage: 240-240 V

• Frequency: 50-60 Hz

• Control voltage: 100-240 V

• Nominal power (resistive load): 5-300 W

• Nominal power (inductive load): 5-300 VA

• Nominal power (capacitive load): 5-75 VA

• Max. switching power (LED): 200 W

• Connection type: Screwed terminal

• Cable section: 1-4 mm²

• Device dimensions:

• Width: 86 mm

• Height: 86 mm

• Depth: 57 mm

• Built-in depth: 33.9 mm

• Min. depth of built-in installation box: 35 mm

• Operating / setting temperature: -5 to 35 °C

• Storage temperature: -20 to 70 °C

• Voltage type: AC

• Mandatory neutral: No

• Terminal marking indication: Yes

• Stress test conformity (1000V): Yes

• Antimicrobial treatment: No

• Terminals capacity: 1-4 mm²

• Cable nature for connection: Flexible or rigid

• Compatible with:

• Apple HomeKit: No

• Google Assistant: No

• Amazon Alexa: No

• IFTTT: No
