Technical characteristics

• Assembly arrangement: Basic element with full cover plate

• Method of operation: Turn button

• Wiring system: Other

• Mounting method: Flush-mounted

• Material: Metal

• Material quality: Aluminium

• Halogen free: Yes

• Surface protection: Untreated

• Surface finishing: Matt

• Colour: Black

• Transparent: No

• Suitable for degree of protection (IP): IP20

• Rated current: 0.42 A

• Nominal voltage: 240 V

• Type of fastening: Mounting with screw

• Minimum depth of built-in installation box: 40 mm

• Dimensions:

• Width: 86 mm

• Height: 54 mm

• Depth: 86 mm

• Built-in depth: 33.2 mm

• Degree of impact strength (IK): IK04

• Operating / setting temperature: -5 to 35 °C

• Storage temperature: -20 to 70 °C

• Voltage type: AC

• Frequency: 50-60 Hz

• Terminal marking indication: Yes

• Connection type: Screwed terminal

• Number of terminals: 2

• Terminals capacity: 1-4 mm²

• Cable nature for connection: Flexible or rigid

• With socket outlet: No

• Label space/information surface: No
