The product's benefits

Advantages

• Definite motion for a soft touch and sound
• Technicity and Robustness of the support frame
• Thin and modern design for a perfect decoration integration

Technical characteristics

• Assembly arrangement: Basic element with complete housing

• Model: Single push button

• Method of operation: Rocker

• Contactless type: No

• Number of rockers: 1

• Number of poles: 1

• Nominal voltage: 250 V

• Rated current: 10 A

• With lighting: No

• With light source: No

• Feedback-signal contact: No

• Connection type: Screwed terminal

• Mounting method: Flush-mounted

• Type of fastening: Screw mounting

• Material: Metal

• Material quality: Aluminium

• Halogen free: Yes

• Antimicrobial treatment: No

• Surface protection: Untreated

• Surface finishing: Matt

• Colour: Black

• RAL-number (similar): 9003

• Transparent: No

• Label space/information surface: Yes

• Imprint: Symbol "bell"

• Suitable for degree of protection (IP): IP20

• Degree of impact strength (IK): IK04

• Device width: 86 mm

• Device height: 86 mm

• Device depth: 34.6 mm

• Min. depth of built-in installation box: 35 mm

• Compatible with Apple HomeKit: No

• Compatible with Google Assistant: No

• Compatible with Amazon Alexa: No

• IFTTT support available: No

• Built-in depth: 24.9 mm

• Operating / setting temperature: -5 to 50 °C

• Storage temperature: -10 to 70 °C

• Voltage type: AC

• Frequency: 50-60 Hz

• Mandatory neutral: Yes

• Terminal marking indication: Yes

• Terminals capacity: 1-4 mm²

• Cable nature for connection: Flexible or rigid

• Cable section: 1-4 mm²
