Technical characteristics

• Wiring system: Off switch 1-pole

• Method of operation: Rocker lever

• Assembly arrangement: Basic element with full cover plate

• Push button switch: No

• Number of rockers: 1

• Mounting method: Flush-mounted

• Type of fastening: Screw mounting

• With mounting plate: Yes

• Material: Plastic

• Material quality: Thermoplastic

• Halogen free: Yes

• Antimicrobial treatment: No

• Surface protection: Lacquered

• Surface finishing: Matt

• Colour: Black

• Colour of switch operator: Black

• Illumination: No

• Suitable for degree of protection (IP): IP20

• Degree of impact strength (IK): IK04

• Nominal voltage: 250 V

• Rated current: 16 A

• Switching current for fluorescent lamps: 16 AX

• Feedback-signal contact: No

• Connection type: Screwed terminal

• Heating switch: No

• Washing machine switch: No

• Device width: 86 mm

• Device height: 86 mm

• Device depth: 36.8 mm

• Built-in depth: 24.9 mm

• Min. depth of built-in installation box: 35 mm

• Compatible with Apple HomeKit: No

• Compatible with Google Assistant: No

• Compatible with Amazon Alexa: No

• IFTTT support available: No

• Operating / setting temperature: -5 to 50 °C

• Storage temperature: -10 to 70 °C

• Voltage type: AC

• Frequency: 50-60 Hz

• Mandatory neutral: No

• Terminal marking indication: Yes

• Terminals capacity: 1-4 mm²

• Cable nature for connection: Flexible or rigid

• Cable section: 1-4 mm²
